DSJ SERIES DRYING HAMMER MILLS
Product Display
PRODUCT DATA
Technical Data of DSJ Series Drying Hammer Mills:
| Model | Max Feed Size(mm) | Capacity(t/h) | Water content of feed material | Motor Power(kw) | Weight(t) |
| DSJ1515 | ≤100 | 20-25 | ≤15% | 75 | 29 |
| DSJ2015 | ≤100 | 30-35 | ≤15% | 132 | 40 |
| DSJ2020 | ≤100 | 35-40 | ≤15% | 132 | 45.5 |
| DSJ2515 | ≤100 | 40-50 | ≤15% | 160 | 55 |
| DSJ2817 | ≤100 | 65-80 | ≤15% | 315 | 78 |
| DSJ3026 | ≤100 | 110 | ≤15% | 600 | 128 |
| DSJ4325 | ≤100 | 150-160 | ≤15% | 800 | 145 |
The production capacity of the listed crusher is based on the measurement results of instantaneous sampling of medium hardness materials. The above data are for reference only, please contact our engineers for equipment selection of specific project.
DSJ SERIES DRYING HAMMER MILL BRIEF INTRODUCTION
In gypsum board industry, the rotor on DSJ Series Drying Hammer crusher can break up and throw the desulfurized gypsum slag, whose water content is no more than 28%. During this process, the gypsum slag exchanges the heat with the intake hot air of 550°C, and then the max water content of the material is 1%, which goes into riser from outlet duct and then hot air takes the material into the next process. This machine can also be used to dry and crush filtered cake in cement industry and calcium carbide slag in environmental protection.
DSJ Series Drying Hammer crusher adopt reasonable and reliable process technology, high-quality material and advanced automated processing equipment which ensures the reliable and steady operation, and convenient maintenance. Each environmental indicators of this equipment are in line with the requirements of the country.
Desulfurized gypsum slag used to be processed through the landfill, which seriously pollutes the environment and uses the farmland. Nowadays, the desulfurized gypsum slag can be used as construction gypsum powder after being processed by this machine. What's more, its performance is better than that of natural gypsum. It is high-quality raw material to produce gypsum board.
